How AADC Works

The Problem

Many computational workloads repeat the same sequence of operations thousands or millions of times. Pricing derivatives. Computing risk sensitivities. Training ML models.

Traditional approaches re-interpret every operation on every run. Tape-based AAD stores millions of operations in memory.

Neither takes advantage of modern CPU capabilities. Gradients cost 2-5× extra computation time.

The Solution

AADC records your calculation once at runtime. It then generates a highly optimised binary kernel tailored to your specific problem.

These kernels run on standard hardware with full vectorization and automatic multithreading. No interpretive overhead. No tape.

The kernel executes 6× to 1000× faster. Gradients often compute faster than the original function alone.

Works with QuantLib, time-series ML, and scientific simulations.

The Transformation

YOUR CODE TODAY

Exotic pricing 2-5 seconds

Greeks Bump & revalue (+593% overhead)

Cloud bill $$$$$

Optimization Manual, ongoing

YOUR CODE WITH AADC

Exotic pricing 20-50ms

Greeks Automatic AAD (+31% overhead)

Cloud bill $ (50-99% savings)

Optimization Automatic

Same codebase. Same models. Transformed performance.

BENCHMARK

See the Minimal Code Changes Required

This Monte Carlo pricing example illustrates typical AADC integration. The same pattern applies to any numerical code — finance, ML, scientific computing.

420x

faster than basic Python

73x

faster Greeks than NumPy

+83

lines of code added

+32%

AAD overhead for all Greeks

Compare implementations below. The AADC version adds minimal wrapper code while delivering dramatic speedups and automatic derivatives.

basic.py - gbm_constants ~16 hours 739 total lines
 def gbm_constants(r, sigma, T, num_timesteps):
    """Compute GBM simulation constants."""
    dt = T / num_timesteps
    sqrt_dt = math.sqrt(dt)
    drift = (r - 0.5 * sigma * sigma) * dt
    vol_sqrt_dt = sigma * sqrt_dt
    return dt, sqrt_dt, drift, vol_sqrt_dt

basic.py - simulate_path ~16 hours 739 total lines
 def simulate_path(S0, K, r, T, drift, vol_sqrt_dt, Z_path, num_timesteps):
    """Simulate GBM path and compute discounted payoff."""
    price = S0
    running_sum = 0.0
    for t in range(num_timesteps):
        price = price * math.exp(drift + vol_sqrt_dt * Z_path[t])
        running_sum += price

    average = running_sum / num_timesteps
    payoff = max(average - K, 0.0)
    discount = math.exp(-r * T)
    discounted_payoff = discount * payoff
    return discounted_payoff

basic.py - price_asian_option ~16 hours 739 total lines
 def price_asian_option(S0, K, r, sigma, T, Z, num_scenarios, num_timesteps):
    """Price Asian option - loop over all scenarios."""
    dt, sqrt_dt, drift, vol_sqrt_dt = gbm_constants(r, sigma, T, num_timesteps)

    payoff_sum = 0.0
    for scenario in range(num_scenarios):
        payoff_sum += simulate_path(S0, K, r, T, drift, vol_sqrt_dt,
                                    Z[scenario], num_timesteps)

    return payoff_sum / num_scenarios

basic.py - price_with_greeks ~16 hours 739 total lines
 def price_with_greeks(S0, K, r, sigma, T, Z, num_scenarios, num_timesteps):
    """Compute price and Greeks via bump-and-revalue (4 pricings)."""
    bump = 1e-6
    price = price_asian_option(S0, K, r, sigma, T, Z, num_scenarios, num_timesteps)
    delta = (price_asian_option(S0 + bump, K, r, sigma, T, Z, num_scenarios, num_timesteps) - price) / bump
    rho   = (price_asian_option(S0, K, r + bump, sigma, T, Z, num_scenarios, num_timesteps) - price) / bump
    vega  = (price_asian_option(S0, K, r, sigma + bump, T, Z, num_scenarios, num_timesteps) - price) / bump
    return price, delta, rho, vega

# Greeks require 4 full pricings - 4x the compute cost!

aadc_pricer.py - gbm_constants 136s 822 total lines
 def gbm_constants(r, sigma, T, num_timesteps):
    """Compute GBM simulation constants."""
    dt = T / num_timesteps
    sqrt_dt = np.sqrt(dt)
    drift = (r - 0.5 * sigma * sigma) * dt
    vol_sqrt_dt = sigma * sqrt_dt
    return dt, sqrt_dt, drift, vol_sqrt_dt

# Identical to naive - AADC works with regular Python code!

aadc_pricer.py - simulate_path 136s 822 total lines
 def simulate_path(S0, K, r, T, drift, vol_sqrt_dt, Z_vals, num_timesteps):
    """Simulate GBM path and compute discounted payoff."""
    price = S0
    running_sum = aadc.idouble(0.0)                                  # AADC
    for t in range(num_timesteps):
        price = price * np.exp(drift + vol_sqrt_dt * Z_vals[t])
        running_sum = running_sum + price

    average = running_sum / num_timesteps
    payoff = np.maximum(average - K, 0.0)
    discount = np.exp(-r * T)
    discounted_payoff = discount * payoff
    return discounted_payoff

# Only change: aadc.idouble for running_sum - enables AAD!

aadc_pricer.py - price_asian_option 136s 822 total lines
 def price_asian_option(S0, K, r, sigma, T, Z, num_scenarios, num_timesteps, num_threads=4):
    """Price Asian option using AADC - loop over all scenarios."""
    workers = aadc.ThreadPool(num_threads)                           # AADC

    # --- Record computation graph ---
    funcs = aadc.Functions()                                         # AADC
    funcs.start_recording()                                          # AADC

    # Active variables (use idouble instead of float)
    S0_v    = aadc.idouble(S0);    S0_arg    = S0_v.mark_as_input()   # AADC
    r_v     = aadc.idouble(r);     r_arg     = r_v.mark_as_input()    # AADC
    sigma_v = aadc.idouble(sigma); sigma_arg = sigma_v.mark_as_input()# AADC
    K_v     = aadc.idouble(K);     K_arg     = K_v.mark_as_input_no_diff()  # AADC
    T_v     = aadc.idouble(T);     T_arg     = T_v.mark_as_input_no_diff()  # AADC

    # ... record path simulation ...

    payoff_res = discounted_payoff.mark_as_output()                  # AADC
    funcs.stop_recording()                                           # AADC

    # Evaluate vectorized across scenarios
    request = {payoff_res: [S0_arg, r_arg, sigma_arg]}               # AADC
    results = aadc.evaluate(funcs, request, inputs, workers)         # AADC

    return results, payoff_res, S0_arg, r_arg, sigma_arg

aadc_pricer.py - price_with_greeks 136s 822 total lines
 def price_with_greeks(S0, K, r, sigma, T, Z, num_scenarios, num_timesteps, num_threads=4):
    """Compute price and Greeks via AAD (1 forward + 1 adjoint pass)."""
    results, payoff_res, S0_arg, r_arg, sigma_arg = price_asian_option(
        S0, K, r, sigma, T, Z, num_scenarios, num_timesteps, num_threads
    )

    # --- Extract results ---                                        # AADC
    discounted_payoffs = results[0][payoff_res]                      # AADC
    price = float(np.mean(discounted_payoffs))                       # AADC

    # Greeks from single adjoint pass (no extra pricings needed!)    # AADC
    delta = float(np.mean(results[1][payoff_res][S0_arg]))           # AADC
    rho   = float(np.mean(results[1][payoff_res][r_arg]))            # AADC
    vega  = float(np.mean(results[1][payoff_res][sigma_arg]))        # AADC

    return price, delta, rho, vega

# All Greeks computed in ONE pass - +31% overhead vs +593%!

optimised.cpp - gbm_constants 731s 877 total lines
 void gbm_constants(double r, double vol, double T, size_t num_timesteps,
                   double& dt, double& sqrt_dt, double& drift, double& vol_sqrt_dt) {
    /**Compute GBM simulation constants.*/
    dt = T / static_cast<double>(num_timesteps);
    sqrt_dt = std::sqrt(dt);
    drift = (r - 0.5 * vol * vol) * dt;
    vol_sqrt_dt = vol * sqrt_dt;
}

optimised.cpp - simulate_path 731s 877 total lines
 // Scalar version (portable, works on ARM/Apple Silicon)
double simulate_path_scalar(double S0, double K, double drift, double vol_sqrt_dt,
                            const double* Z_row, size_t num_timesteps) {
    /**Simulate GBM path and compute payoff (scalar version).*/
    double price = S0;
    double running_sum = 0.0;

    for (size_t t = 0; t < num_timesteps; ++t) {
        price = price * std::exp(drift + vol_sqrt_dt * Z_row[t]);
        running_sum += price;
    }

    double average = running_sum / static_cast<double>(num_timesteps);
    double payoff = std::max(average - K, 0.0);
    return payoff;
}

// AVX2 SIMD version also available for x86-64 (~2x faster)

optimised.cpp - price_asian_option 731s 877 total lines
 // Core pricing function (auto-selects AVX2 or scalar)
double price_asian_option(
    double S0, double K, double r, double vol, double T,
    const double* Z, size_t num_scenarios, size_t num_timesteps
) {
    double dt, sqrt_dt, drift, vol_sqrt_dt;
    gbm_constants(r, vol, T, num_timesteps, dt, sqrt_dt, drift, vol_sqrt_dt);

#if USE_AVX2
    // Broadcast constants to SIMD registers
    const __m256d drift_vec = _mm256_set1_pd(drift);
    const __m256d vol_sqrt_dt_vec = _mm256_set1_pd(vol_sqrt_dt);
    const __m256d S0_vec = _mm256_set1_pd(S0);
    size_t row_stride = (num_timesteps + SIMD_WIDTH - 1) & ~(SIMD_WIDTH - 1);
#else
    size_t row_stride = num_timesteps;
#endif

    double payoff_sum = 0.0;
    for (size_t scenario = 0; scenario < num_scenarios; ++scenario) {
        const double* Z_row = Z + scenario * row_stride;
#if USE_AVX2
        payoff_sum += simulate_path_avx(S0, K, drift, vol_sqrt_dt, Z_row, num_timesteps,
                                        drift_vec, vol_sqrt_dt_vec, S0_vec);
#else
        payoff_sum += simulate_path_scalar(S0, K, drift, vol_sqrt_dt, Z_row, num_timesteps);
#endif
    }

    return std::exp(-r * T) * (payoff_sum / static_cast<double>(num_scenarios));
}

optimised.cpp - price_with_greeks 731s 877 total lines
 // Greeks via bump-and-revalue (requires 4 full pricings)
constexpr double BUMP_SIZE = 1e-6;

void price_with_greeks(
    double S0, double K, double r, double vol, double T,
    const double* Z, size_t num_scenarios, size_t num_timesteps,
    double& price, double& delta, double& rho, double& vega
) {
    price = price_asian_option(S0, K, r, vol, T, Z, num_scenarios, num_timesteps);
    double p_dS = price_asian_option(S0 + BUMP_SIZE, K, r, vol, T, Z, num_scenarios, num_timesteps);
    double p_dr = price_asian_option(S0, K, r + BUMP_SIZE, vol, T, Z, num_scenarios, num_timesteps);
    double p_dv = price_asian_option(S0, K, r, vol + BUMP_SIZE, T, Z, num_scenarios, num_timesteps);
    delta = (p_dS - price) / BUMP_SIZE;
    rho   = (p_dr - price) / BUMP_SIZE;
    vega  = (p_dv - price) / BUMP_SIZE;
}

// Even with AVX2 SIMD, Greeks add +582% overhead (7 evaluations)!

Key insight: AADC delivers 420x faster than Basic Python and 73x faster Greeks than NumPy — outperforming hand-optimised C++ by 5.4x.

Greeks via AAD: 1 forward + 1 adjoint pass - +32% overhead vs +306% for NumPy bump-and-revalue.

View Full Benchmark Details See All Benchmarks

What Practitioners Say

Antoine Savine

Author, Modern Computational Finance

MatLogica offers a unique AAD engine, bundled with a purposely developed just-in-time compiler, whereby banks can effortlessly optimize existing code with AAD, into machine code optimized for modern hardware. Because of this optimizing compiler, Matlogica's offering currently stands way above competition. I have seen the results and they are truly impressive.

Senior Quant

Tier-2 European Bank

One notable feature of AADC is that complex model calibration procedures do not require any special attention as is often the case with other AAD approaches. For example, we 'AADC-record' simple Dupire volatility calculations, regression-based continuation value calibration and even Monte-Carlo based Cheyette model calibrations, with no special care needed to back-propagate adjoints. This has allowed us to eliminate a large amount of complex and hard to maintain code.

Luigi Ballabio

Co-founder and Administrator, QuantLib

I've been very impressed by performance gains up to two orders of magnitude obtained by MatLogica after some integration work on QuantLib, and by the fact that the same work also enabled AAD; especially considering that the library contains hundreds of thousands of lines of code developed over more than 20 years.

Sid Dash

Chief Researcher at Chartis Research (2025)

MatLogica's suite of tools enables acceleration and scalability in both analytical and quantitative code.The transformational nature of MatLogica's offering is reflected in its top 15 placing in the QuantitativeAnalytics50, alongside several awards for innovation in computational frameworks and code acceleration.

MatLogica AADC - Frequently Asked Questions

What is MatLogica AADC?

MatLogica AADC (Automatic Adjoint Differentiation Compiler) is a just-in-time graph compiler that delivers 6-100x performance improvements for quantitative finance applications. It automatically generates optimized binary kernels with AVX2/AVX512 vectorization and computes derivatives (Greeks) efficiently using Automatic Adjoint Differentiation.

How much faster is AADC compared to traditional methods?

AADC delivers 6-100x speedup compared to traditional implementations. In benchmarks, AADC Python achieves 444× faster performance than Basic Python and 4.6× faster Greeks calculation than hand-optimized C++ with AVX2 SIMD intrinsics.

What programming languages does AADC support?

AADC supports C++, Python, and C#. The Python integration allows you to write simple Python code that runs at C++ speeds without requiring SIMD expertise or manual vectorization.

What is Automatic Adjoint Differentiation (AAD)?

Automatic Adjoint Differentiation (AAD) is a technique for computing derivatives efficiently. Unlike bump-and-revalue which requires N+1 function evaluations for N Greeks, AAD computes all derivatives in a single forward pass plus one adjoint (backward) pass, regardless of the number of sensitivities needed.

What industries use MatLogica AADC?

MatLogica AADC is used primarily in quantitative finance for derivatives pricing, risk management (XVA, VaR, FRTB), and trading systems. It's also used in machine learning, scientific computing, and any field requiring fast gradient computation.

How long does AADC integration take?

AADC integration is straightforward since it uses a drop-in replacement for native types. For prototyping, you can see results in hours. For production systems, typical integration takes 2-3 weeks for initial results.

What is the ROI of implementing AADC?

Clients typically see 80-95% reduction in cloud computing costs, 10x faster time-to-market for new models, and significant developer productivity gains. The ROI calculator on our website can estimate savings for your specific use case.

How does AADC compare to GPU-based solutions?

AADC on CPU often outperforms GPU solutions for many quant finance workloads due to lower latency, no data transfer overhead, and better handling of complex control flow. AADC also doesn't require specialized GPU programming skills or hardware.

Your Pricing and Risk Models.
6× to 1000× Faster.
Automatic Greeks.

How AADC Works

The Problem

The Solution

What You Can Expect

Unlock Superior Performance Across Trading, Risk, and Technology Roles

Front Office

Risk Management

Quant Technology

What MatLogica Does

The Transformation

See the Minimal Code Changes Required

Choose Your Implementation Path

Legacy Optimization

Greenfield Development

Open-Source Acceleration

Cloud Optimization

What Practitioners Say

Example: Live Risk System

Turn Batch into Real-Time

Calculate Your Savings

Book a Call

Your Pricing and Risk Models.6× to 1000× Faster.Automatic Greeks.

How AADC Works

The Problem

The Solution

What You Can Expect

Unlock Superior Performance Across Trading, Risk, and Technology Roles

Front Office

Risk Management

Quant Technology

What MatLogica Does

The Transformation

See the Minimal Code Changes Required

Choose Your Implementation Path

Legacy Optimization

Greenfield Development

Open-Source Acceleration

Cloud Optimization

What Practitioners Say

Example: Live Risk System

Turn Batch into Real-Time

Calculate Your Savings

Book a Call

Your Pricing and Risk Models.
6× to 1000× Faster.
Automatic Greeks.
